Intraocular Tumors – Melanocytic

Home / Ophthalmic Pathology / Intraocular Tumors

Differential Diagnosis of iris nodules

  • Iris pigment epithelial cysts -encompass both layers of iris and produce localized stromal elevation. May need B-scan or trans-illumination to see.
  • Iris pigment epithelial proliferation results from congenital or acquired (trauma/surgery) –composed of plaques of pigment epithelium –black, velvety color.
    • Juvenile xanthogranuloma -yellow/grey iris lesions with orange skin
    • Lesions in 1st yearof life.
    • Assoc. 1. with spontaneous hyphema
    • Secondary glaucoma
    • Diffuse granulomatous reaction with lipid filled histiocytes and touton giant cells Regress spontaneously
  • Leiomyoma
    • localized or diffuse, pedunculated or flat
    • Electron microscopy required to differentiate from amelanotic spindle cell melanoma
  • Leukemia -very rare
    • Nodularor diffuse milky lesions with intense hyperemia.
    • Pseudohypopyon
    • Iris loses architecture and becomes thickened.
  • Lisch Nodules
    • one of the diagnostic criteria for NF-1
    • Multiple flat or raised tan to brown lesions
    • Composed of collections of nevus cells
  • Malignant melanoma
    • Nodular of flat –usually peripheral
    • 80% inferior + inferotemporal
    • May have nutrient vessel, satellite pigmentation
    • Pupil may dilate irregularly
  • Melanocytosis
    • Unilateral, heterochromia irides
    • May have oculodermal form with eyelid + brow involved
    • Has malignant potential
  • Retinoblastoma
    • White foci on iris surface or in angle
    • May have pseudohypopyon
    • Retinoblastoma present in posterior chamber
  • Tapioca Melanoma
    • Often associated with unilateral glaucoma.
    • Tapioca-like nodules over part or all of iris
  • Metastatic Carcinoma
    • Gelatinous to white vascularized nodules on iris surface.
    • May be associated with anterior uveitis, glaucoma, rubeosis, and hyphema.

Iris Nevus:

Mamalis Tumor 01 unlabeled  Mamalis Tumor 01 labeled

17.01 External slit lamp photo

Mamalis Tumor 02 unlabeled  Mamalis Tumor 02 labeled

17.02 Spindle nevus

Mamalis Tumor 03 unlabeled  Mamalis Tumor 03 labeled

17.03 Borderline spindle nevus

Mamalis Tumor 04 unlabeled  Mamalis Tumor 04 labeled

17.04 Epithelioid nevus

  • Darkly pigmented lesion of iris stroma
  • minimal distortion of normal architecture
  • circumscribed > typically nodular + discrete
  • diffuse > may involve entire sector or even entire iris
  • increased incidence in NF –1
  • most common in Caucasian background (97%)(1)
  • ABCDEF guide for risk factors 1–risk of nevus transformation to melanoma increases for the following:
    • A –age –younger age is higher risk
    • B –blood –hemorrhage is common in melanoma
    • C –clock hour inferiorly –inferior location is higher risk
    • D –diffuse configuration –diffuse nevus more likely for malignant transformation
    • E–ectropion –ectropion uvea increases risk
    • F –feathery margin

Iris Melanocytoma:

  • Dark pigmented brown lesion –may have granular “mound of black sand” appearance.(1)
  • Usually stable and does not require intervention
  • May have spontaneous necrosis –which can liberate pigment into anterior chamber and cause glaucoma.
  • In one series of 47 patients, 48% showed mild growth and 63% showed new tumor seeds, but none (0%) showed malignant transformation(4).

Iris Melanoma:

Mamalis Tumor 05 unlabeled  Mamalis Tumor 05 labeled

17.05 External slit lamp photo

Mamalis Tumor 06 unlabeled  Mamalis Tumor 06 labeled

17.06 Spindle melanoma

Mamalis Tumor 07 unlabeled  Mamalis Tumor 07 labeled

17.07 Epithelioid melanoma

Mamalis Tumor 08 unlabeled  Mamalis Tumor 08 labeled

17.08 Mixed melanoma

Nick’s Tips: When small iris melanoma may be impossible to differentiate from nevus –may consider biopsy done through clear cornea.

  • Risk of metastasis is about 3%,(5) much less commonly fatal than other choroidal melanomas possibly due to
    • Earlier diagnosis and usually smaller at diagnosis
    • Most commonly spindle cell type(over 50%)
    • May have other unique features
  • Least common site of primary uveal melanoma (about 3-10%).(6)
  • Associated with: (6)
    • Light iris color
    • Inferior location
    • Average age 40 years old (younger than choroidal melanoma (age 50))
  • May appear circumscribed (melanotic nodule) or diffuse (heterochromia), with diffuse having a somewhat poorer prognosis.
  • Histopathologic features:
    • Typically spindle uveal melanoma cells –
      • Plump nucleus,
      • Eosinophilic nucleolus visible,
      • Mildly coarse chromatin
  • Some are mixed cell type (combination of spindle and epithelioid
  • Epithelioid –
    • Abundant eosinophilic cytoplasm and distinct cell borders
    • Large nucleus
    • Central nucleolus
    • Larger and more pleomorphic than spindle cells.
  • Signs of iris melanoma:
    • Ectropion iris
    • Prominent Vascularity
    • Sectoral cataract
    • Secondary glaucoma
    • Progressive growth
    • Extrascleral extension
    • Seeding of angle
    • Large size
    • ¾ of iris melanomas involve inferior iris
    • Unilateral glaucoma
    • Spontaneous hyphema
  • Treatment
    • Excision
    • Brachytherapy
    • Proton beam

Iris Cysts:

Mamalis Tumor 09 unlabeled  Mamalis Tumor 09 labeled

17.09 Iris stromal cyst

  • Imaging:(2)
    • Ultrasound (UBM) –better at imaging posterior wall and overall imaging of structure
    • Anterior Segment OCT –better at imaging anterior surface of lesion
  • Types of iris cysts
    • Stromal cysts
      • may be congenital or acquired
      • usually smooth, translucent mass on in in the iris
      • may have debris inside cyst
      • may rupture –can cause iritis or glaucoma if ruptured
      • Congenital stromal cysts in children under age 10 tend to be more aggressive and may have poor visual outcome.
      • Treatment –may surgically remove or may aspirate cyst and sclerose with absolute alcohol.(3)
    • Pigmented epithelial cysts
      • Usually asymptomatic
      • Darkly pigmented –arising from posterior surface of the iris
      • May resemble ciliary body melanoma or iris pigmented epithelial adenoma, clinically.
      • UBM and anterior segment OCT may help demonstrate cystic nature of lesion.

Nevus of choroid / ciliary body

Mamalis Tumor 10 unlabeled  Mamalis Tumor 10 labeled

17.10 Fundoscopic photoof nevus

Nick’s Tips: Although no single feature differentiates a malignant melanoma and a choroidal nevus, virtually all melanocytic tumors greater than 3mm thick are melanomas and virtually all melanocytic lesions less than 1mm thick are Nevi.

  • Choroid nevus –7% of population –flat or minimally elevated
  • May be amelanotic or grey-black
  • Differential diagnosis of a pigmented fundus Lesion
    • Nevus
    • Melanoma
    • Atypical disciform scar
    • Suprachoroidal hemorrhage
    • RPE hyperplasia
    • CHRPE
    • Melanocytoma
    • Choroidal osteoma
    • Hemangioma with RPE changes
    • Metastatic tumor with RPE changes
  • Risk of melanoma
    • Increased with thickness > 1 mm
    • Increased with diameter > 10mm
    • (<10mm almost always benign)
    • Visual symptoms
    • Orange pigment
    • Subretinal fluid
    • Large size >1mm thick, >10mm diameter
    • Juxtapapillary
    • Absence of drusen or RPE changes
    • Hot spots on FA
    • Homogeneity on ultrasound
    • Enlargement

Melanocytoma:

Mamalis Tumor 11 unlabeled  Mamalis Tumor 11 labeled

17.11 Ciliary body melanocytoma

  • Rare, large polyhedral shaped cells with small nuclei + melanin.
  • May seed A/C causing glaucoma
  • In choroid, they appear like nevis or melanoma on exam
  • May undergo malignant changes.
  • If growth is documented, treat as malignant.

Melanoma of ciliary body/choroid:

Mamalis Tumor 12 unlabeled  Mamalis Tumor 12 labeled

17.12 Ciliary body melanoma

Mamalis Tumor 13 unlabeled  Mamalis Tumor 13 labeled

17.13 External slit lamp photo

Mamalis Tumor 14 unlabeled  Mamalis Tumor 14 labeled

17.14 Gross cross-section of globe

Mamalis Tumor 15 unlabeled  Mamalis Tumor 15 labeled

17.15 Tumor arising from ciliary body

Mamalis Tumor 16 unlabeled  Mamalis Tumor 16 labeled

17.16 Tumor arising in ciliary body coming into trabecular meshwork

Mamalis Tumor 16 unlabeled  Mamalis Tumor 17 labeled

17.17 Choroidal Melanoma

Mamalis Tumor 18 unlabeled  Mamalis Tumor 18 labeled

17.18 Spindle cell A choroid

Mamalis Tumor 19 unlabeled  Mamalis Tumor 19 labeled

17.19 Spindle cell B choroid

Mamalis Tumor 20 unlabeled  Mamalis Tumor 20 labeled

17.20 Epithelioid choroid

Mamalis Tumor 21 unlabeled  Mamalis Tumor 21 labeled

17.21 Mixed melanoma choroid

Nick’s Tips:

Histopathology of Choroidal Melanoma/Nevus:

  • Six types:
    • Spindle nevus
    • Spindle nevus with plaque
    • Borderline spindle nevus
    • Spindle melanoma
    • Epithelioid nevus
    • Epithelioid melanoma
  • Prognosis from histological features –poor outcomes due to metastasis via scleral emissary channels
    • Pure spindle B –good prognosis
    • Mixed is intermediate prognosis
    • Epithelioid is poor prognosis

Clinical Features of Choroidal Melanoma

  • Most common primary intraocular malignancy in adults 6-7 cases per million.
  • Primary affects patients aged 50’s-60’s
  • Risk factors:
    • Light complexion, light irides
    • Ocular melanocytic conditions
    • Melanosis oculi, oculodermal melanocytosis
    • Genetic predisposition (dysplastic nevus syndrome)
    • Cigarette smoking
  • May be clinically silent + large when detected.
  • Symptoms may include
    • Vision loss or decreased vision
    • Changes in or decreased visual field
    • Photopsias
    • May have no symptoms
  • Appearance:
    • May rarely erode through sclera or iris + become visible on external exam
    • Initial sign of ciliary body melanoma may be dilated episcleral sentinel vessels.
    • Ring Melanoma → 360° -180° melanoma of ciliary body.
    • Pigmented, elevated dome shaped.
    • May be amelanotic to dark brown.
    • May erupt through Bruch’s membrane + make mushroom shape.
    • Orange pigment clumps may form @ RPE level.
    • Serous detachment of retina is common
    • Neovascularization, hemorrhage, lens subluxation are late complications
    • Vitreous hemorrhage only if penetrated through Bruch’s
  • Diagnostic Evaluation:
    • Indirect ophthalmoscopic evaluation-#1 technique.
    • Gonioscopy –best method for establishing anterior involvement
    • High-frequency ultrasound for iris + ciliary body evaluation
    • B-scan u/s →for tumor measurement, extrascleral extension
    • A-scan u/s →for internal reflectivity (characteristic low internal reflectance –homogenous)
    • Transilluminationmay help identify tumor
    • Wide angle fundus photography.
    • FA does NOT have characteristic appearance.
    • CT + MRI may help in opaque media
  • Differential diagnosis:
    • choroidal nevus: usually flatter + smaller
    • ARMD with pigmented scar –fluorescein angiographypathognomic –hemorrhage rare in melanoma
    • CHRPE –well defined, flat dark lesion-histology → tall melanin containing RPE cells that are histologically identical to bear tracks.
    • Melanocytoma of the optic disc.
      • Has minimal malignant potential
      • Lesion is located peripapillarily.
      • 10% will show growth over 5 years
      • May produce vision and visual field defects due to nerve fiber layer disruption
    • Suprachoroidal Detachments:
      • May be hemorrhagic orserous.
      • Associated with hypotony.
      • Often dome shaped, associated with breakthrough vitreous hemorrhage.
      • Usually located in multiple quadrants
      • Usually treated with observation
    • Choroidal Osteoma:
      • Benign bony tumors. Yellow to orange, well defined
      • Arise from juxtapapillary choroid
      • Adolescent to young adults
      • High amplitude echo on u/s from bony plate with shadowing behind lesion.
      • Calcification on CT scan.
      • Typically slow growing over years
      • May affect vision if in macula or nearby
      • Etiology unknown, may be related to low-grade inflammation
      • Subretinal neovascularization common

Classification of Melanomas:

Nervus <5mm diameter <2mm thick
Small 5-10mm 2-3mm thick
Medium 10-15mm 3-5mm
Large 15-20mm 5-10mm
Extra Large >20mm >10mm



  • Metastasis up to 50% at 25yrs, 25% at 5yrs, 34% at 10yrs (COMS Study)Less than 2% have clinically detectable metastatic disease at time of diagnosis. Median survival less than 6months with metastatic disease.Liver 1st site of metastasis, 89% on clinical exam 100% on autopsy. Lung, 24% on clinical exam 50% on autopsy; skin, 12% on clinical exam 50% on autopsy; bone possible later 17% on clinical exam 50% on autopsy.

    • Clinical Evaluation: (yearly follow-up)
      • Liver ultrasound
      • Liver function tests (LFTs)
      • Chest X-ray (low yield)
      • If any are positive tests, then Tri-phasic liver CT, CT or MRF of chest + abdomen.
      • Metastases can develop up to 20 years after treatment.
    • Treatment: little evidence of natural history exists.
      • If metastasis found, then enucleation is NOT appropriate.
      • Much of the treatment protocols were developed from the results of the COMS trial –a randomized prospective treatment study of choroidal melanoma.
      • Methods of treatment depend on
        • Size, location, extent
        • vision of affected + fellow eye
        • age + general health
    • Treatment Protocols:
      • Observation:
        • small melanoma <1mm thick
        • Elderly or otherwise short life expectancy
      • Enucleation: Gold-standard for treatment
        • Does NOT disseminate tumor secondary to manipulation.
        • Appropriate for all medium to extra-large tumors
      • Brachytherapy: most common method of treating uveal melanoma.
        • High dose, localized radiation. Usually I125, Ruthenium106 plaques
        • Local control rates >96%
        • Optic neuropathy + radiation retinopathy in 50%-Location + dose dependent complications
    • Charged particle radiation: proton beam.
      • Requires tantalum localization clips.
      • Up to 98% local control. Increased radiation dose to anterior segment.
    • External Beam Radiation: can be used in conjunction with enucleation or brachytherapy.
    • Other Alternative Treatments:
      • Photoablation + hyperthermia → subretinal fluid treated with grid laser: leads to increase in tumor growth due to rupture of Bruch’s membrane
      • Transpupillary Thermotherapy –associated with decrease in tumor volume.
      • Cryotherapy –not thought to be effective
      • Transcleral diathermy –contraindicated–provides route for extrascleral extension
      • Surgical excision: may have success, but difficult + margins are very important.
      • Chemotherapy: Not effective for treatment, but may be palliative
      • Immunotherapy: under investigation
      • Exenteration: rarely employed, but may be used in cases with extrascleral extension.
    • Prognosis: 5yr mortality:
      • 50% for large
      • 30% for medium
      • 12% for small
    • Risk factors for mortality:
      • Large tumor
      • Growth
      • Anterior tumor location
      • Extraocular extension
      • Older age
      • Tumor regrowth after ocular conservation therapy
      • Rapid decrease in size after globe conserving treatment
      • Juxtapapillary tumors.
      • Histopathological Features associated with increased mortality
        • Epithelioid cells
        • High mitotic index
        • Complex microvascular patterns
        • Large nuclei
        • Tumor infiltrating lymphocytes
        • Monosomy 3
        • Trisomy 8
    • Collaborative Ocular Melanoma Study.
      • 1003 patients with large or extra-large choroidal melanomas
        • Greater than 16mm diameterand/or greater than 10mm thick
        • Comparedenucleation to enucleation + external beam
        • 5-yr survival 57%with enucleation versus 62% with external beam
        • No improvement with radiation over enucleation alone.
      • 1317 patients with medium-sized choroidal melanoma
        • Tumor size: 6mm-15mm diameter and/or 2.5-10mm thick. Compared enucleation with brachytherapy
        • No difference in mortality (18% for enucleation and 19%for brachytherapy)
        • 43% had visual acuity worse than 20/200 with brachytherapy
        • Small ↑ in mortality with tumor recurrence
      • 204 patients with small choroidal melanoma
        • 4-8mm wide x 1-2.5mm thick
        • Mortality 1% at 5 years
      • COMS Study risk factors for growth
        • Increased thickness + diameter @ presentation
        • Orange pigment
        • No drusen or RPE changes
        • Pinpoint hyperflourescence on FA

    Pigmented Epithelial Tumors of Uvea + Retina:

    • Adenoma:
      • (benign) very rare
      • Oval, deeply melanotic tumors arising abruptly from RPE
      • Rarely undergo malignancy change.
    • Adenocarcinoma:
      • very, very rare
      • Malignantpotential very low.
    • Ciliary Cysts
      • Opacified ciliary cysts associated with multiple myeloma and macroglobulinemia

    Fuchs’ Adenoma

    Mamalis Tumor 22 unlabeled  Mamalis Tumor 22 labeled

    17.22 Fuch’s adenoma

      • Usually incidental finding @ autopsy.
      • Glistening white irregular tumor from ciliary crest.
      • Benign proliferation of non-pigmented epithelium
    • Acquired Hyperplasia: RPE + ciliary pigmented epithelium may
      • Proliferate in response to trauma or surgery.
      • may mimic choroidal melanoma
      • Treatmentis to observe.
    • Combined Hamartoma:
      • Rare–occurs at the disc margin. Dark pigmented, minimally invasive lesion
      • Proliferation of RPE, glial, + blood vessels
      • May cause retinal traction.
      • May have more or less pigment
      • May be mistaken for melanoma.

    Angiomatous Tumors

    Choroidal Hemangioma

    • Circumscribed choroidal hemangiomas are not associated with systemic disorders
    • Red/orange tumor, often in macula
    • Often produces secondary retinal detachment
    • Often affect overlying RPE with degeneration of outer retina.
    • Differential diagnos is
      • Amelanotic choroidal melanoma
      • Choroidal osteoma
      • Metastatic carcinoma
      • Granuloma of choroid.

    Diffuse choroidal Hemangioma associated with Sturge –Weber Syndrome

    • Diffuse reddish-orange thickening of retina
    • Tomato catsup fundus.
    • Retinal detachmentcommon
    • Glaucoma common.
    • FA shows large choroidal vessels, in pre arterial + arterial phases and late staining of tumor. NOT pathognomonic. U/S shows high internal reflectivity, acoustic heterogeneity. No shadowing. CT scan can be helpful in differentiating from osteoma. Treatment:
      • observation if asymptomatic
      • Serous detachment (including fovea) → photocoagulation
        • Treating withlight laser to adhere retina + ↓ serous fluid.
        • Recurrent detachments common.
        • PDT → to entire lesion may involute tumor + ↓ fluid.
        • Brachytherapy, Proton Beam, Gamma Knife have been used to involute tumor as well.
        • Periocular + intraocular avastin is being investigated.

    Retinal Angiomas:

    Capillary Hemangioma

    Mamalis Tumor 23 unlabeled  Mamalis Tumor 23 labeled

    17.23 Capillary hemangioma in Von Hippel –Lindau syndrome

    • Rare, autosomal dominant (1 in 40,000)
    • Diagnosis at age 10-30.
    • Orange/red tumor arising in retina with tortuous vessels.
    • Subretinal exudates common + often in fovea.
    • Exudate detachment common.
    • “Von Hippel disease”
      • familial in 20%
      • Bilateral in 50%
    • Von Hippel–Lindau Syndrome choroidal hemangioma with associated with cerebellar hemangioblastoma
    • Genetics
      • Gene located on chromosome 3
      • Associated tumors
        • Retinal capillary hemangioma
        • Cerebellar hemangioblastoma
        • Renal Cell Carcinoma
        • Pheochromocytoma
      • Genetic screening can help determine risk of tumors,
    • FA shows feeding arteriole, massive network + draining venule.
    • Treatment:
      • Photocoagulatesmall lesions.
      • Cryotherapy for larger, peripheral lesions.
      • Penetrating diathermy for very large lesions.
      • Avastin isbeing investigated.

    Cavernous Hemangioma

    Mamalis Tumor 24 unlabeled  Mamalis Tumor 24 labeled

    17.24 Cavernous hemangioma

    • Uncommon, cluster of grapes lesion.
    • Generally not associated with exudates.
    • Small hemorrhages + gliosis may appear on surface.
    • May occur on optic disc.
    • FA is diagnostic–fills slowly fluorescein + RBCs separate.
    • No vitreous leakage (unlike Coats Disease or capillary hemangioma)
    • No treatment necessary for cavernous hemangioma.
    • Composed of dilated, thin walled vessels, interconnected

    A-V malformation

    A-V malformation:

    • Racemose Hemangioma (congenital retinal A-V malformation)
    • Range from small vascular communication near disc or periphery
    • To large tangle of tortuous vessels throughout fundus.

    Wyburn-Mason:

    • Racemose hemangioma + midbrain A-V malformation.
    • Associated A-V malformations possible in orbit+ mandible

    Retinoblastoma

    Mamalis Tumor 25 unlabeled  Mamalis Tumor 25 labeled

    17.25 Retinoblastoma

    Mamalis Tumor 26 unlabeled  Mamalis Tumor 26 labeled

    17.26 Gross cross-section globe of RB

    Mamalis Tumor 27 unlabeled  Mamalis Tumor 27 labeled

    17.27 Exophytic growth pattern of RB

    Mamalis Tumor 28 unlabeled  Mamalis Tumor 28 labeled

    17.28 Endophytic growth pattern

    Mamalis Tumor 29 unlabeled  Mamalis Tumor 29 labeled

    17.29 Necrosis

    Mamalis Tumor 30 unlabeled  Mamalis Tumor 30 labeled

    17.30 Dystrophic calcification

    Mamalis Tumor 31 unlabeled  Mamalis Tumor 31 labeled

    17.31 Flexner-Wintersteiner rosettes

    Mamalis Tumor 32 unlabeled  Mamalis Tumor 32 labeled

    17.32 Alcian blue stain

    Mamalis Tumor 33 unlabeled  Mamalis Tumor 33 labeled

    17.33 Fleurette

    Mamalis Tumor 34 unlabeled  Mamalis Tumor 34 labeled

    17.34 Vitreous seeding

    Mamalis Tumor 35 unlabeled  Mamalis Tumor 35 labeled

    17.35 Tumor invading optic nerve

    Nick’s Tips: The differential diagnosis of leukocoria in a child and specifically the details of retinoblastoma is one of the most high yield study subject for the Boards. In addition, this material may enable you to save a child life someday.

    Retinoblastoma:

    • #1 most common primary malignancy of childhood.
    • 2nd most common primary malignancy (behind uveal melanoma) in all age groups.
    • 1 in 14,000-20,000, 300 new cases/year in USA.
    • No gender predilection
    • 30% to40%bilateral.
    • Age @ diagnosis:
      • Family history of known retinoblastoma→ 4months
      • Bilateral disease → 14 months
      • Unilateral disease →24 months
      • 90% by age 3.
    • Genetics: mutation in retinoblastoma tumor suppressor gene.
      • 6% familial
        • 98% chance of germline mutation in bilateral disease.
        • Children of retinoblastoma survivor have 45% chance of having retinoblastoma (50% transmission, 90% penetrance)
      • 94% sporadic.
        • About 60% have unilateral disease
          • No germline mutation
          • Most have unifocal tumor
        • 40% have new germline mutation + multifocal disease.
      • About 95% chance of finding germline mutation with genetic testing.
    • Presentation:
      • Leukocoria = most common presentation
      • Strabismus + ocular inflammation also possible.
    • Clinical Appearance
      • Begins as grey/translucent intraretinal tumor with dilated feeder vessels
      • Becomes chalky white as calcification occurs.
      • Serous retinal detachment may occur as tumor grows + cause ↓ vision + difficulty visualizing tumor.
      • Exophytic tumors: grow beneath retina → retinal detachment
      • Endophytic tumors:
        • Grow on retinal surface into vitreous.
        • Vitreous seeding more common
        • May seed Anterior chamber leading to
          • Pseudohypopyon
          • Rubeosis + secondary to glaucoma in 50%
      • Diffuse –infiltrating retinoblastoma:
        • Appears like intermediate uveitis with diffuse vitreous cells,
        • Poor view of retina.
      • Metastatic
        • Most common metastasis is through direct extension via optic nerve.
        • May extend into subarachnoid space.
        • May also erode through sclera or emissary veins into orbit.
        • In A/C, may invade trabecular meshwork + lymphatics.
        • Metastatic to:
          • Skull bones, distant bones
          • Brain, spinal cord
          • Lymph nodes (preauricular/cervical)
          • Abdominal viscera
      • Clinical Exam:
        • Need exam under anesthesia with scleral depression.
        • Document clearly location + size of multiple tumors.
        • Ultrasound may show calcifications
        • MRI is imaging modality of choice for globe, ON, brain.
        • Systemic evaluation not necessary if no signs of extraocular extension.
        • LP if extensionvia ON thought to have occurred
        • Examine siblings + parents
      • Differential Diagnosis of Leukocoria:
        • Retinoblastoma
        • Coats disease
        • Astrocytic hamartoma –tuberous sclerosis
        • Retinal capillary hemangiomatosis
        • Granulomas (especially associated with nematode endophthalmitis) -toxocariasis
        • Coats
        • Persistent fetal vasculature
        • Ocular toxocariasis
        • Retinopathy of prematurity
        • Retinal detachment
        • Coloboma
        • Myelinated nerve
        • Toxoplasmosis
        • Retinal dysplasia
        • Trisomy13 → cartilage in ciliary body
        • Norrie’s disease
        • Retinoschisis
        • Cataract (torch, congenital)
        • Cyclitic membrane
        • Medulloepithelioma
        • Incontinenti pigmenti

    Coats Disease:

    Mamalis Tumor 36 unlabeled  Mamalis Tumor 36 labeled

    17.36 Fundoscopic photo

    Mamalis Tumor 37 unlabeled  Mamalis Tumor 37 labeled

    17.37 Gross cross-section globe

    Mamalis Tumor 38 unlabeled  Mamalis Tumor 38 labeled

    17.38 Telangiectasic vessels leak into retina and under retina

    Mamalis Tumor 39 unlabeled  Mamalis Tumor 39 labeled

    17.39 Processed specimen leaving sickle shaped cholesterol plaques

    • male>female (10:1)
    • poor visual prognosis
    • Unilateral retinal telangiectasias, yellow exudates.
    • No distinct mass, (cholesterol rich sickle shaped spaces)
    • Fluid leakage may lead to serous retinal detachment which may be large
    • Ultrasound documents absence of retinal tumor.
    • Treat with laser or cryo of vascular anomalies to decrease serous detachments

    Persistent Fetal Vasculature (Persistent hyperplastic primary vitreous):

    Mamalis Tumor 40 unlabeled  Mamalis Tumor 40 labeled

    17.40 External slit lamp photo

    Mamalis Tumor 41 unlabeled  Mamalis Tumor 41 labeled

    17.41 Mass in the lens pulls and contracts ciliary processes forward.

    Mamalis Tumor 42  Mamalis Tumor 42 labeled

    17.42 Remnant hyaloid artery

    Mamalis Tumor 43 unlabeled  Mamalis Tumor 43 labeled

    17.43 Bergmeister papillae

    Mamalis Tumor 44 unlabeled  Mamalis Tumor 44 labeled

    17.44 Gross cross-section glob

    Mamalis Tumor 45 unlabeled  Mamalis Tumor 45 labeled

    17.45 PHPV

    Mamalis Tumor 46 unlabeled  Mamalis Tumor 46 labeled

    17.46 Remnant Hyaloid artery

    • Typically recognized in 1st few weeks of life
    • Unilateral in 2/3
    • Associated with
      • Microphthalmos.
      • Shallow anterior chamber
      • Hypoplastic iris
      • Retrolenticular mass of fibrovascular tissue
    • Vascular stalk may be seen arising from nerve.
    • May have closed funnel retinal detachment
    • Ultrasound shows no tumor, short axial length +/-calcification
    • Treatment is vitrectomy/lensectomy.

    Ocular Toxocariasis:

Mamalis Tumor 47 unlabeled  Mamalis Tumor 47 labeled



17.47 Toxocariasis

    • Most patients have a history of soil ingestion or exposure to puppies.
    • Posterior mass + peripheral granulomas + uveitis.
    • Ultrasound shows vitritis, granuloma, retinal traction, NO calcification
  • Astrocytoma: (astrocytic hamartoma)
    • Small, white, glistening tumor of nerve fiber layer
    • Sometimes large, mulberry appearance with calcification.
    • Usually arise from optic disc (termed “giant drusen”)
    • Common in tuberous sclerosis + may occur in neurofibromatosis
    • Usually ∅assoc. with phakomatosis.
  • Retinocytoma: clinically indistinguishable from retinoblastoma
    • Histologically benign.
    • Same genetic implications as retinoblastoma
    • Unclear developmental biology.
  • Reece-Ellsworth classification of intraocular retinoblastoma.
  • Predicts eye preservation when treated with external beam radiation.
A B
Group I (very favorable) solitary tumor <4DD multiple tumors
II 4-10DD multiple 4-10DD
III at equator or anterior >10DD posterior
IV multiple tumors, some >10DD anteriorto ora serrata
V(least favorable) massive tumor > ½ retina vitreous seeding

International Classification

A Small(<3mm) >3mm from fovea >1.5mm from optic nerve
B (>3mm) confined to retina
C Localizedvitreous or subretinal seeding. <6mm from tumor
D Diffuse vitreous or subretinal seeding. >6mm from primary
E No visual potential or tumor in anteriorsegment, in or onciliary body, neovascular glaucoma,vitreous hemorrhage, phthisical eye, orbital extension/proptosis.



  • Trilateral Retinoblastoma:
    • bilateral intraocular retinoblastoma + ectopic intracranial retinoblastoma.
    • Ectopic foci usually in pineal gland. (pinealoblastoma)
    • Occurs in 2-5% with germline mutation.
    • Usually pineal
    • blastoma presents years after retinoblastoma, but may present before.
    • Often show Flexner-Wintersteiner rosettes on histology.
    • Embryological evidence for photoreceptor differentiation in pineal glando
    • All retinoblastoma patients should undergo neuroimaging.
    • Serial MRI with and without contrast = best (No radiation exposure)
    • Decreased incidence of trilateral retinoblastoma with chemo –may be prophylactic.
    • Median survival 8 month with CNS involvement.
  • Prognosis:
    • 95% survival if contained in eye
    • Less than 50% survival if extraocular spread.
  • Treatment:
    • Goals
      • #1 preserve life,
      • #2 preserve eye,
      • #3 preserve vision.
    • Enucleation: definitive treatment. Usually enucleate if any of the following:
      • Tumor >50% of eye
      • Orbitalor ON involvement suspected
      • Anterior segment involved
    • Chemotherapy:
      • carboplatin, vincristine, etoposide, cyclosporine
      • IV treatment Q3-4 weeks in 4-9 cycles.
      • Decrease tumor volume + finish treatment with laser, cryo, radiation.
    • Periocular Chemo: in phase 1 + 2 trials, shows promise.
    • Photocoagulation + hyperthermia:
      • May kill tumor blood supply
      • Cytotoxic effect of heat.
      • Small tumors.
    • Cryotherapy
      • Small tumors <10mm diameter, <3mm thick.
      • Anterior location (laser for posterior)
      • Repetitive treatment+ close follow up.
    • External Beam:
      • retinoblastomais radiation responsive.
      • 4,000 –4,500 cGy over 4-6 wks.
      • Typically are bilateral not amenable to cryo or laser.
      • 85% of globes retained.
      • Visual function limited only by tumor location and secondary complications.
    • Concerns:
      • Retinoblastoma mutation associated with lifelong increased risk of osteosarcoma
      • Risk of osteosarcoma is exacerbated by exposure to external beam radiation
      • Midface hypoplasia
      • Cataract
      • Radiation optic
      • Neuropathy + other radiation side effects.
    • Combination therapy may decrease radiation and its secondary complications.
  • Brachytherapy: salvage therapy for some eyes
  • Primary treatment for amenable eyes with small-medium tumors.
  • Adenovirus targeted gene therapy in trials → makes tumor susceptible to ganciclovir –via Thymidine Kinase transfection
  • Spontaneous Regression:
    • May undergo complete necrosis + regression.
    • Sometimes seen in phthisical eyes.
    • Vitreous filled with islands of calcified cells in mass of fibrovascular connective tissue.
    • Associated with exuberant proliferation of RPE + ciliary body
    • Ghost contours of tumor cells.
  • Prognosis:
    • Survival greater than 95% with access to modern care.
    • Extraocular extension is the most important poor prognostic factor
    • Bilateral diseasemay have decreased survival secondary to optic intracranial foci
    • Bilateral retinoblastoma leads to increased incidence of other tumors
    • Mean time = 9 years
    • 26% develop another tumor in 50 yrs.
    • External beam radiation decreased latency and increased head + neck tumors.
    • Most common secondary tumor = osteogenic sarcoma
    • Also pinealoma, brain tumor, melanoma, sarcoma, primitive tumors
      • 10-20% will develop tumor in 20 years
      • 30-40% will develop 3rd tumor in 30 years
      • Survival <50% in those who develop 2° osteogenic sarcoma.

Secondary Tumors

Metastaticintraocular tumors:

Mamalis Tumor 48 unlabeled  Mamalis Tumor 48 labeled

17.48 Fundoscopic photo

Mamalis Tumor 49 unlabeled  Mamalis Tumor 49 labeled

17.49 Lung cancer metastasized to choroid

Nick’s Tips:

  • Metastases are the most common intraocular tumors in adults
  • Metastases are the most common orbital tumors in adults

Mets to Eye

Males Females
Lung 40% Breast 68%
Unknown 29% Lung 12%
GI 9% Unknown 12%
Kidney 6% Others 4%
Prostate 6% GI 2%
Skin 4% Skin 1%
Others 4% Kidney<1%



  • Choroid is 10-20 x more likely location for metastases, due to higher blood supply than iris or ciliary body
  • Metastases to the retina + optic disc rare
  • Bilateral in 20-25%
  • Metastases are often yellow/white/grey, may have RPE changes
  • Metastases to the posterior pole may cause decreased visual acuity
  • Rarely break through Bruch’s membrane
  • May cause retinal detachment over tumor
  • Necrosis + uveitis possible
  • Diagnosis:
    • FA pattern of double circulation + early filling seen in choroidal melanomas is rare in metastatic tumors
    • Ultrasound is helpful,
      • A-scan shows moderate to high reflectivity (melanoma = low)
    • Fine needle aspiration biopsy may help, but metastases may be too poorly differentiated to identify.
  • Metastases to retina are very rare:
    • Appear as white, non-cohesive lesions
    • May appear similar to cotton wool spots
    • May vitreous seed + appear like retinitis.
  • Previous diagnosis versus unknown cancer diagnosis:
    • Breast cancer
      • 70-90% with metastatic ocular or orbital breast tumor to uvea have a history of breast CA diagnosis + treatment.
      • If no prior diagnosis of breast cancer, then refer for breast exam
    • Lung cancer
      • Lung metastases often do not have prior diagnosis.
      • Poor prognosis if uveal metastasis. Mean survival 1-67 mo
  • Prognosis: Depends on primary tumor.
    • Lung + GI is worst prognosis
    • Carcinoma+ breast cancer is better prognosis
  • Treatment: depends on many factors
    • Goals
      • Maintain vision
      • Palliate pain.
    • Types:
      • Systemic chemo or hormone treatment
      • Laser, cryo, beam radiation, etc….
      • Enucleation with unrelenting pain.
  • Avenue of entrance to the orbit or globe
    • Hematogenous inoculation is by far the most common
      • Breast, lung, GI, and others
    • Direct intraocular extension is rare because the sclera is a good barrier.
      • Squamous cell carcinoma from conj. = most common
      • Conj. Melanoma
      • Basal cell of eyelid possible

Lymphomatous Tumors

Intraocular lymphoma:

Mamalis Tumor 50 unlabeled  Mamalis Tumor 50 labeled

17.50 Lymphoma

  • Type:
  • Almost always Non-Hodgkin, B-cell, large cell.
  • T-cell = rare.
  • May invade any part of eye/orbit.
  • Source:
  • Most common = primary CNS lymphoma (25% have intraocular involvement) Vitreous + retina involved
  • Rarely Systemic/visceral/nodal lymphoma: usually uveal tract + choroid.
  • Making the diagnosis
  • Any bilateral or chronic uveitis age over 50 should consider lymphoma.
  • Diffuse vitreous cells, headlight in fog appearance.
  • Complete neuro exam will be positive of deficiencies in 10% of patients
  • 60% will have central nervous system involvement –should do
  • CT
  • MRI
  • LP
  • Diagnostic vitrectomy.
  • Pathology
  • Flow cytometry
  • PCR
  • Immunohistochemical stains
  • Treatment
  • Limited by blood-ocular barrier.
  • Irradiation with external beam –tumor invariably reoccurs.
  • Intraocular methotrexate → good response, low recurrence
  • CNS treatment by oncologist
  • Prognosis: poor, requires close f/u

Uveal Lymphoid Infiltration:

  • Uveal Lymphoid Infiltration: (reactive lymphoid hyperplasia) –unknown etiology
  • May occur at any site. –benign lymphoid infiltration
  • Painless progressive vision loss
  • Diffuse amelanotic thickening of choroid
  • Exudative retinal detachment+ glaucoma in 85%, proptosis 15% due to orbit infiltration
  • Treatment: high dose steroid, fractionated radiation
  • Excellent prognosis

Leukemia

  • Ocular involvement common –up to 80% on autopsy
  • Up to 40% at diagnosis.
  • Retinal lesions most commonly found, choroid is most common site.
  • Choroid may act as sanctuary for leukemic cells
  • Eye may be 1st sentinel of reactivation
  • Ultrasound may be better than indirect ophthalmoscopy.
  • May involve iris with small nodules @ pupil margin or diffuse thickens
  • May have pseudohypopyonor 2° glaucoma.
  • Retinal findings include:
    • hard exudates
    • CWS
    • Pseudo-Roth spots.
    • Yellow deposits in retina,
    • Grey nodules in CML
    • Perivascular streaks
  • Vitreous involvement rare –use diagnostic vitrectomy if suspected
  • Optic Nerve infiltration is anophthalmic emergency, treatment required immediately –treat with systemic + intrathecal chemo. +/-radiation
  • Proptosis possible if orbital soft tissue infiltrates.
  • May have opportunistic infections secondary to immunocompromise.
  • Treatment = low dose radiation, systemic chemotherapy

Medulloepithelioma:

  • Meulloepithelioma (diktyoma)
    • Tumor of non-pigmented Ciliary Body epithelium
    • Has benign + malignant forms
    • Congenital
    • Clinical diagnosis usually around age 4-12 years old. Sometimes diagnosed in adults
    • Variably pigmented mass arising from ciliary body (rarely on orinretina)
    • May erode into anterior chamber
    • Treatment
      • Enucleate–DO NOT SURGICALLY RESECT
      • Observe
      • Metastasisis RARE
      • May treat small lesions with brachy therapy (I-125 plaque)

Leiomyomas, Neurilemomas, Neurofibromas:

VERY RARE: Usually misdiagnosed as amelanotic primary uveal melanomaand discovered on histopathology

References:

  1. Shields CL, Shields PW, Manalac J, Jumroendararasame C, Shields JA. Review of cystic and solid tumors of the iris. Oman J Ophthalmol, 2013 Sep-Dec; 6(3):159-164.
  2. Bianciotto C, Shields CL, Guzman JM, Romanelli-Gobbi M, Mazzuca D Jr, Green WR, Shields JA Assessment of anterior segment tumors with ultrasound biomicroscopy versus anterior segment optical coherence tomography in 200 cases. Ophthalmology. 2011 Jul; 118(7):1297-302.
  3. Shields CL, Arepalli S, Lally SE, Lally EB, Shields JA. Iris stromal cyst management with alcohol-induced sclerosis in 16 patients. JAMA Ophthalmol. 2014 Jun;132(6):703-8.
  4. Demirci H, Mashayekhi A, Shields CL, Eagle RC, Shields JA. Iris Melanocytoma: clinical features and natural course. Am J Ophthalmol. 2005 Mar; 139(3):468-75.
  5. Geisse LH, Robertson DM. Iris Melanoma. Am J Ophthalmol 1985. 99:638-648.
  6. Henderson E, Margo C. Iris Melanoma. Archives of Pathology & Laboratory Medicine. 2008 Feb 132(2):268-272.
